Bi-Level Microwave Motion Sensor
Volume Discounts automatically applied for orders $500+
Free Shipping on orders $100+
Ships within 1 business dayExperience advanced lighting control with the Bi-Level Microwave Motion Sensor. This microwave sensor enhances the energy efficiency and adaptability of your high bays and canopy lights based on various factors. When insufficient ambient brightness is detected, it can turn on a light fixture and keep it at standby dimming level. This means the fixture will only turn on or off based on the light available in its environment. It also keeps lights off even when motion is detected because the environment has sufficient daylight. Plus, this smart sensor activates lights upon motion detection within its range. These capabilities not only save energy but also offer responsive lighting solutions for diverse settings. With its robust design and wet rating, this light and motion detector is ideal for large spaces such as warehouses or factories.
Features
- Max. 39ft/12m mounting height & 9ft/≥3m detection distance
- Compatible with 4 optional receptacles that can partner with all light fixtures
- Includes daylight threshold and dusk-to-dawn functionality
- Bi-Level dimming capabilities
- IP65 wet rated
- RoHS Compliant & UL certified
- 5-year manufacturer's warranty
Default sensor settings:
- Detection area: 100%
- Holdtime: 5sec
- Daylight threshold: disable
- Stand-by period: 0sec
- Stand-by dimming level: 10%
- Operating temperature: -40°F~+140°F
Compatible Fixtures
| JNL-SS-GP04-100W-H-TCP3550-Y (LED Canopy) |
Overview
Experience advanced lighting control with the Bi-Level Microwave Motion Sensor. This microwave sensor enhances the energy efficiency and adaptability of your high bays and canopy lights based on various factors. When insufficient ambient brightness is detected, it can turn on a light fixture and keep it at standby dimming level. This means the fixture will only turn on or off based on the light available in its environment. It also keeps lights off even when motion is detected because the environment has sufficient daylight. Plus, this smart sensor activates lights upon motion detection within its range. These capabilities not only save energy but also offer responsive lighting solutions for diverse settings. With its robust design and wet rating, this light and motion detector is ideal for large spaces such as warehouses or factories.
Features
- Max. 39ft/12m mounting height & 9ft/≥3m detection distance
- Compatible with 4 optional receptacles that can partner with all light fixtures
- Includes daylight threshold and dusk-to-dawn functionality
- Bi-Level dimming capabilities
- IP65 wet rated
- RoHS Compliant & UL certified
- 5-year manufacturer's warranty
Default sensor settings:
- Detection area: 100%
- Holdtime: 5sec
- Daylight threshold: disable
- Stand-by period: 0sec
- Stand-by dimming level: 10%
- Operating temperature: -40°F~+140°F
Compatible Fixtures
| JNL-SS-GP04-100W-H-TCP3550-Y (LED Canopy) |
Details
MOTION & DAYLIGHT ACTIVATED
This convenient, responsive to both motion and daylight, and easily installed Microwave Motion Sensor detects movement and lights to automate lighting in your warehouse, office building, or other commercial spaces. Use this to only illuminate when necessary. Great for safety purposes to detect movement after hours.
INCREASE ENERGY SAVINGS
Attached motion sensor turns on your light only when you need it to reduce your wattage consumption.
BENEFITS
5-year manufacturer's warranty. Sunco is proudly based in the USA, offering quality products at affordable prices backed by industry-leading warranties and knowledgeable support specialists.
CERTIFICATIONS
We uphold the highest standards by testing each product for optimal performance and safety. This daylight and motion sensor is RoHS Compliant & UL certified.
Specifications
| Bi-Level Microwave Motion Sensor Specifications
Download Specs |
|
|---|---|
| Brand | NSL |
| Operating Temperature | -40°F - 140°F |
| Dimmable | Dimmable |
| Dimming Details | 0-10V Dimming |
| IP Rating | IP65 |
| Moisture Rating | Wet Rated |
| Motion Sensor | Yes |
| Sensor Details | See specification sheet for full details about motion detection. |
| Certifications | RoHS, UL |
| Warranty | 5-Year Manufacturer's Warranty |
